PRODUCT CLASSIFICATION

Model: TBN032-TBN400DA/SR, 17 models, aluminium with hard anodized body, output torque 7.4-8033Nm at 5 bar air supply, ISO5211/DIN3337 to match valve connection, Namur interface for the accessories, ±5°adjustment, with CE/ ATEX certification.

The Electro-Pneumatic Positioner YT-1000 is used for operation of pneumatic rotary or linear valve actuator by means of electrical controller of control systems with an analog output signal of DC 4 to 20mA or split ranges.

• There is no resonance at 5-200Hz.

• The change of RA/DA acting is convenient.it is able to apply to apply to single or double acting actuator.

• It is possible to prevent the hunting with orifice to the small size actuator.

• It is economical due to less air consumption.

• It is able to control the 1/2 split range with simple operation with replacement of parts.

As a major part of automation control system, KH series manual override is widely used with pneumatic actuators in combination. It's mainly used for 90°rotary ON/OFF valve, such as butterfly valve, ball valve, plug valve. The manual override make it possible to manual operation when the pipeline is air failure.

Features

High-strength, high torque

Weatherproof: IP65

Mounting base standard: ISO5211KH SERIES MANUAL OVERRIDE

Model: BQ600,13 models, output torque 60Nm ~ 6000N.m, aluminum alloy housing with epoxy coated, ON/OFF type, Modulating type, ISO5211, Explosion proof EXDIIBT4 for option, with CE certification.

The APL Series Limit Switch Box is a compact, weather proof enclosure with internal adjustable position switches and an external visual indication. It has NAMUR standard mounting and drive, and is ideally suited for mounting on to quarter turn actuators and valves.

The APL Series Limit Switches features:

• Solid and compact design aluminium die-cast housing with polyester powder coated finish.

• Bolt-on Visual Position Indicator.

• “Quick-Set” spring loaded splined cam. No need to adjust again after initial setting. Easy setting without tools.

• Dual cable entries.

• Captive cover bolts to prevent loss when cover is removed.

• NAMUR standard stainless steel shaft and bracket.

Feature:

– Superior regulation characteristics.

– Rugged and corrosion-resistant construction

– Excellent stability and repeatability.

– Self-Relieving.

– Low drop at high flow.

– Intergral,self cleaning filter.

– Several mounting options.

ACTION: Electromagnet or manual, press and rotate the slider to realize manual operation manual state lock.

Reset way: Pneumatic spring return, mechanical spring return, electromagnet operation restoration.

Connection: ISO228/1or G1/4

Working Temperature： -20℃～+60℃

Material: The valve body and internal parts: anodized aluminum alloy, copper.Cover: strengthening plastic. Sealing ring: styrenebutadiene rubber (NBR) and the polyurethane (AU).

mount: Accord with NAMUR standard and VDI/VDE3845 double holes.

Electric pressure: 24VDC, 24V/110V/220VAC, 6V～110VDC, 12V～254VAC, 50or60Hz

Voltage bias: ±10% standard and explosion-proof (Exd Ⅱ BT4) coil standard coil:AC power six VA, stable starting power

ACTION: Electromagnet or manual, press and rotate the slider to realize manual operation manual state lock.

Reset way: Pneumatic spring return, mechanical spring return, electromagnet operation restoration.

Connection: ISO228/1or G1/4

Working Temperature: -20℃～+60℃

Material: The valve body and internal parts: anodized aluminum alloy, copper.Cover: strengthening plastic. Sealing ring: styrenebutadiene rubber (NBR) and the polyurethane (AU).

mount: Accord with NAMUR standard and VDI/VDE3845 double holes.

Electric pressure: 24VDC, 24V/110V/220VAC, 6V～110VDC, 12V～254VAC, 50or60Hz

Voltage bias: ±10% standard and explosion-proof (Exd Ⅱ BT4) coil standard coil:AC power six VA, stable starting power

Power 4.3 VA (hot state) DC2.6 W (hot state), 3 W (cold state)

Star reduction adaptor/ square adaptor, WCB, 304ss, 316ss material

1. 11mm(Star Outside)×9mm(Square Inside)×12mm(height)

2. 14mm(Star Outside)×9mm(Square Inside)×15mm(height)

3. 14mm(Star Outside)×11mm(Square Inside)×16mm(height)

4. 17mm(Star Outside)×11mm(Square Inside)×19mm(height)

5. 17mm(Star Outside)×14mm(Square Inside)×17mm(height)

6. 19mm(Star Outside)×11mm(Square Inside)×21mm(height)

7. 19mm(Star Outside)×14mm(Square Inside)×21mm(height)

8. 19mm(Star Outside)×17mm(Square Inside)×21mm(height)

9. 22mm(Star Outside)×14mm(Square Inside)×20mm(height)

10. 22mm(Star Outside)×17mm(Square Inside)×24mm(height)

11. 22mm(Star Outside)×19mm(Square Inside)×20mm(height)

12. 27mm(Star Outside)×17mm(Square Inside)×29mm(height)

13. 27mm(Star Outside)×19mm(Square Inside)×29mm(height)

14. 27mm(Star Outside)×22mm(Square Inside)×29mm(height)

15. 36mm(Star Outside)×19mm(Square Inside)×29mm(height)

16. 36mm(Star Outside)×22mm(Square Inside)×38mm(height)

17. 36mm(Star Outside)×27mm(Square Inside)×38mm(height)
